ALLCLEAN® Series
Maximum Hygiene
Our ALLCLEAN® series progressive cavity pumps are stainless steel CIP pumps for demanding media. They feature a high quality stainless steel design for easy cleaning and maintenance. The ALLCLEAN® pump series is used in various industries where hygiene is an indispensable quality factor. The various mounting and installation options make the ALLCLEAN® suitable for a wide range of applications. The eccentric screw pump can be installed in a block design directly in your plant. Alternatively, the pump is available on a base plate or on spherical feet.
Easy Cleaning
Stainless steel design simplifies cleaning and maintenance (CiP)
Hygiene & Product Safety
Highest standards of hygiene and contamination-free conveying
Gentle Conveying
Gentle handling ensures flawless end products
Quick cleaning
CIP Technology
Our ALLCLEAN® pumps are equipped with Cleaning-in-Place (CIP) technology. CIP means that the pump can be cleaned without disassembly by means of continuous flow rinsing. The hydrodynamic design of the pump interior ensures that there are no dead spaces with no product flow. This allows thorough cleaning of all components and piping to remove contaminants and residues that can occur when pumping high-value media such as food, pharmaceuticals or cosmetics.
With CIP, ALLCLEAN® pumps ensure consistent product quality and the highest levels of hygiene and product safety. ALLCLEAN® pumps can help your company increase production efficiency and produce superior products. In addition, the use of stainless steel makes cleaning easier, as the smooth surface prevents dirt and bacteria from adhering, thus facilitating thorough cleaning, including CIP.
AEB-SE & AEB-F-ME
Extremely Robust Design For High Demands In The Food Industry
The closed block design and high-quality materials make them resistant to the special challenges that can occur in food production. When operators need a mobile pump for flexible use at different production sites, the AEB-F-ME is the right choice. If this is not required, operators can choose the very compact AEB-SE.
For Industries With The Most Stringent Hygiene Requirements
Our ALLCLEAN® pumps are indispensable in a variety of industries where hygiene is paramount. In the food industry, for example, they ensure gentle pumping of sauces, fruit concentrates, jams, chocolate or honey, preventing contamination and guaranteeing product quality.
ALLCLEAN® pumps also provide maximum hygiene and safety for dairy products such as milk, yogurt and quark by gently transferring sensitive products and maintaining product integrity. In the pharmaceutical and cosmetics industries, progressive cavity pumps meet high standards of cleanliness and hygiene by conveying ointments and cosmetics without contamination. These versatile pumps are also known for their reliability in the chemical industry, where they handle paints, adhesives, and more to efficiently optimize processes.
| Series | Specifications | Max. Capacity [l/min] |
Max. Differential Pressure [bar] |
Max. Viscosity [mm²/s] |
Max. Fluid Temperature [°C] |
Max. Stages |
|---|---|---|---|---|---|---|
| ACNP | Base Plate Design | 480 | 12 | 150.000 | 130 | 2 |
| ACNBP | Block Design | 480 | 12 | 150.000 | 100 | 2 |
| AEB-SE | Block Design | 900 | 10 | 150.000 | 80 | - |
| AEB-F-ME | Block Design & Mobile | 700 | 6 | 150.000 | 45 | - |
